ELAC
970IWV61W
Speaker (L/R)in-wall
Sens.:90 dBImp.:6ΩConfig:2-wayMount:in-wall
ELAC Vertex Series I IW-V61-W
Retailer Prices
No price availablePrice History
Loading price history...
Related Products
No similar products found.
Specifications
General
| Brand | ELAC |
| Model | 970IWV61W |
| Dimensions (W x H x D) | 8.48 x 12.69 x 3.94" |
Performance
| Sensitivity | 90dBHigh Sensitivity |
| Impedance | 6Ω |
| Freq Response Low | 45Hz |
| Freq Response High | 20000Hz |
| Crossover | 3000Hz |
| Driver Config | 2-way |
Power Handling
| Rec. Power Min | 30W |
| Rec. Power Max | 120W |
| Bi-Amp Capable | No |
Design
| Mounting Type | in-wall |
Installation
| Mounting Depth | 3.94" |
| Cutout Width | 7.36" |
| Cutout Height | 11.61" |
| Back Box Included | No |
| Back Box Required | No |
| Paintable Grille | Yes |
| Magnetic Grille | Yes |
Additional Specs
| Wall Thickness Min | 0.125" |
| Wall Thickness Max | 1" |
| Connector Type | spring-post terminals (bare wire up to 14AWG, pin connectors, single banana plug) |
| Angle Adjustable | No |
| Treble Attenuation Switch | No |
| LCR Capable | No |
| Coaxial | No |
| Moisture Resistant | No |
| UV Resistant | No |
| Salt Spray Rated | No |
| Bracket Included | No |
| Dual Voice Coil (SDI) | No |
